PCB scientist is one of leading printed circuit board manufacturers based in India; PCB Scientist has been offering all sizes with high-quality PCB prototype to production services.

We have facility of an online PCB Price Calculator to allow you get your custom PCB fabrication price within seconds. PCB scientist providing services very fast with quality.

We have following capabilities of Fabrication...

Quality Grade Standard IPC
Number of Layers 1,2 Layers
Order Quantity 1 pc - 10,00 pcs
Build Time 2-7 days (Expedited Service)
Material FR-4 Standard
Board Size Min 6*6 mm | Max 600*700 mm
Board size tolerance ±0.1mm - ±0.3mm
Board Thickness 1 mm - 3.2 mm
Board Thickness Tolerance ±0.2mm - ±10%
Copper Weight 1 oz - 2.0 oz
Min Tracing/Spacing 3 mil/3 mil
Solder Mask Sides As per the file
Solder Mask Color Green, White, Blue, Black, Red, Yellow
Silkscreen Sides As per the file
Silkscreen Color White, Blue, Black, Red, Yellow
Surface Finish HASL Hot Air Solder Leveling
Min Drilling Hole Diameter 0.3 mm
SMD Pitch 0.3 mm
Electrical Test YES
